3. Operation of CON Related Controllers
180
Press Program
Direct Move Screen Status Display List
Name Explanations
1 Cclibration
The loadcell calibration status is shown.
It turns on if calibration has been completed.
2 Cur.pos. The current position is shown.
3 Cur.vel. The current speed is shown.
4 Current load The current load is shown.
5 Analog Output
It shows the analog current output from the MF I/F connector on
the controller in accordance with the current load.
6 Overload level The overload level is shown.
7
Command Current
Rate
The command value of electrical current is shown as a
percentage of the rated current. The current value will be shown
if touchin
the command current rate.
8 Feedbk. Current Rate
It shows the rate of the feedback current to the rated value.
The current value will be shown if touching the feedback current
rate.
9
Command Current
Value
The command current is shown.
The current rate will be shown if touching the command current
value.
10
Feedbk. Current
Value
The feedback current is shown.
The current rate will be shown if touching the feedback current
value.
Press Program
Direct Move Screen Display List
Name Explanations
� Target Pos. (mm) The target position for an axis to be moved can be input.
� Vel. (mm/s) The velocity to move an axis can be input.
To Next Page
