3. Operation of CON Related Controllers
44
[Displayed Items]
PIO pattern The PIO pattern number set to the controller is shown.
Complete pos. No The position number achieved upon completion of positioning is
shown.
IN The status of each input port is shown. ON is lit. OFF is unlit.
OUT The status of each output port is shown. ON is lit. OFF is unlit.
Special input port The statuses of the enable switch, etc., are shown. ON is lit. OFF is
unlit.
Servo The servo ON status is shown. ON is lit. OFF is unlit.
Homing The home return status is shown. Lit, if home return has completed.
Cur. pos. The current position is shown.
Cur. vel. The current speed is shown.
Cur. Shows the command current.
Cur. ratio The command value of electrical current is shown as a percentage of
the rated current.
Alarm code The applicable alarm code is shown.
Controller S/N Shows the manufacturing number of the controller.
The items and buttons to be shown will differ depending on the controller models.
The signal names to be shown will also differ depending on the controller models and operation
patterns.
For Network Type Controllers
Touch [Network Monitor] and the network data monitor window opens.
[Refer to 3.9.1.5]
