8. Use «Up» or «Down» to set the Send/receive value.
8 8 p s i 0 8 : 1 5 A M 1 7 6 ° F
Header
8.1.2.2 SAM 4.0
Menu
Status Counter 0
No error
------------------------------
SAM 4.0 active: ☑
Send/receive
Active line
IP address : 169.254.100.100
9. Press «Enter» to accept the setting.
The setting is applied.
10. Use «Up» or «Down» to select the Starttd line.
8 8 p s i 0 8 : 1 5 A M 1 7 6 ° F
Header
8.1.2.2 SAM 4.0
Menu
IP address : 169.254.100.100
Port : 2000
·········
Communication error : ☑
Start td: 15s
Active line
Timeout : 5s ☑
11. Press «Enter»to switch into setting mode.
The setting mode is active.
12. Use «Up» or «Down» to set the Start td value to 30 s.
8 8 p s i 0 8 : 1 5 A M 1 7 6 ° F
Header
8.1.2.2 SAM 4.0
Menu
IP address : 169.254.100.100
Port : 2000
·········
Communication error : ☑
Start td: 30s
Active line
Timeout : 5s ☑
13. Press «Enter» to accept the setting.
The setting is applied.
Result SIGMA CONTROL 2 communicates with SAM 4.0 via SIGMA NETWORK.
The communication is working smoothly when neither SIGMA CONTROL 2 nor SAM 4.0 report any
communication fault.
8 Initial Start-up
8.10 Configuring the machine for master control
122
User Manual Controller
SIGMA CONTROL 2 SCREW FLUID ≥5.1.2 No.: 9_9450 13 USE
