KAESER SIGMA CONTROL 2 User Manual

4. Press the «Enter» key.
The setting mode is active.
8 8 p s i 0 8 : 1 5 A M 1 7 6 ° F
Header
8.1.2.1 SIGMA CONTROL 2
Menu
Status Run 0 ¦ Error 0
------------------------------
Mode : Master
Active line
Port : 2.001
·········
Communication partner
5. Use the «Up» or «Down» key to set machine 1 to Master .
6. Press the «Enter» key.
The setting is applied.
7. Use «Up» or «Down» to select the IP address line.
8. Press the «Enter» key.
The setting mode is active.
9. Set the IP address of the communication partner (slave, see above example).
10. Press «Enter».
The IP address of machine 2 (slave) is set correctly.
The setting is applied.
Result The controller of machine 1 is set as master.
8.10.4.3 Setting the machine 2 controller as slave
Precondition The electrical connection is made.
Password access level 2 is activated.
Setting the switching points pA and pB
1. Open the 5.2.2 <Configuration – Pressure control – Pressure settings> menu.
The pA line is displayed.
2. Press «Enter».
The value for pA flashes.
8 8 p s i 0 8 : 1 5 A M 1 7 6 ° F
Header
5.2.2 Pressure settings
Menu
Setpoint pressure
pA SP: 123psi ¦ SD: −7.3psi
Active line
pB SP: 119psi ¦ SD: −7.3psi
·········
System pressure low ☐
↓ < 72.5psi ¦ SD: 7.2psi
3. Use «Up» or «Down» to set the pA value.
8 Initial Start-up
8.10 Configuring the machine for master control
136
User Manual Controller
SIGMA CONTROL 2 SCREW FLUID ≥5.1.2 No.: 9_9450 13 USE

KAESER SIGMA CONTROL 2 Specifications

General

Controller Type	Microprocessor-based
Model	SIGMA CONTROL 2
Manufacturer	KAESER
Input Voltage	24 V DC
Protection Class	IP54
Communication Protocols	Modbus, Profibus
Data Logging	Comprehensive data logging
Remote Monitoring	Yes
Communication Interface	Ethernet
