KAESER SIGMA CONTROL 2 User Manual

3. Press «Enter».
The operating mode display flashes.
8 8 p s i 0 8 : 1 5 A M 1 7 6 ° F
Header
5.2.3 Load control
Menu
Local mode: pB
Remote mode : loc.-load RC
Active line
------------------------------
▶1 pA/pB Clock
·········
pA/pB Cycle
4. Use «Up» or «Down» to set the pB input.
5. Press «Enter».
The setting is applied.
6. Adjust the pB nominal pressure, if necessary (see section 8.4).
The local operating mode pB is set.
8.10.6.4 Activating the remote control
➤ Activate remote control see chapter 8.2.13.
Result SIGMA CONTROL 2 remote control is activated.
8.10.6.5 Assign an input for the LOAD remote contact for switching the pressure control
Precondition Password access level 2 is activated.
1. Open the 5.2.3 <Configuration – Pressure control – Load control> menu.
2. Use «Up» or «Down» to select the Load RC line.
3. Press «Enter».
The DI display flashes.
8 8 p s i 0 8 : 1 5 A M 1 7 6 ° F
Header
5.2.3 Load control
Menu
pA/pB RC DI1.05 ☐
Logic : +
pA/pB DO DOR1.04 ☐
Logic : +
·········
Load RC DI1.06 ok ☑
Active line
4. Use «Up» or «Down» to select the input for the LOAD remote contact.
5. Press «Enter».
The input for LOAD remote contact is assigned.
8 Initial Start-up
8.10 Configuring the machine for master control
No.: 9_9450 13 USE
User Manual Controller
SIGMA CONTROL 2 SCREW FLUID ≥5.1.2
143

KAESER SIGMA CONTROL 2 Specifications

General

Controller Type	Microprocessor-based
Model	SIGMA CONTROL 2
Manufacturer	KAESER
Input Voltage	24 V DC
Protection Class	IP54
Communication Protocols	Modbus, Profibus
Data Logging	Comprehensive data logging
Remote Monitoring	Yes
Communication Interface	Ethernet
