KAESER SIGMA CONTROL 2 User Manual

1. Open the 5.7.4 <Configuration – I/O periphery – Switch> menu.
A menu containing a list of available measured values is displayed.
8 8 p s i 0 8 : 1 5 A M 1 7 6 ° F
Header
5.7.4 Switch
Menu
▶1 System pressure pNloc
Active line
▶2 Internal pressure pi
▶3 ADT
▶4 Inlet temperature
▶5 PD temperature
▶6 n Compressor motor
2. Use «Up» or «Down» to select the measured value.
3. Press «Enter».
The menu for the selected measured value (in the example System pressure pNloc ) is dis‐
played.
8 8 p s i 0 8 : 1 5 A M 1 7 6 ° F
Header
5.7.4.1 System pressure pNloc
Menu
active: ☐
Active line with check box
·········
SP: 33.0psi ¦ SD: 0.0psi
Switching point (SP) and switching differential (SD)
td: 0s ¦Logic +
Delay (td) and logic
DOR1.01 ☐
Output DOR
Operation ☐
Type of message
8.11.4.1 Setting the switching point and switching differential
1. Use «Up» or «Down» to select the SP line.
8 8 p s i 0 8 : 1 5 A M 1 7 6 ° F
Header
5.7.4.1 System pressure pNloc
Menu
active: ☐
·········
SP: 7.2psi ¦ SD: −8.7psi
Switching point (SP) and switching differential (SD)
td: 0s ¦Logic +
Delay (td) and logic
DOR1.01 ☐
Output DOR
Operation ☐
Type of message
2. Press «Enter».
The display for the current threshold of the switching point flashes.
3. Use the «Up» or «Down» keys to set the SP threshold.
4. Press «Enter».
The setting is applied.
5. If necessary, adjust the value for the SD switching differential in the same way.
Result The threshold for the SP switching point and the SD switching differential are set.
8 Initial Start-up
8.11 Setting input and output signals
164
User Manual Controller
SIGMA CONTROL 2 SCREW FLUID ≥5.1.2 No.: 9_9450 13 USE

KAESER SIGMA CONTROL 2 Specifications

General

Controller Type	Microprocessor-based
Model	SIGMA CONTROL 2
Manufacturer	KAESER
Input Voltage	24 V DC
Protection Class	IP54
Communication Protocols	Modbus, Profibus
Data Logging	Comprehensive data logging
Remote Monitoring	Yes
Communication Interface	Ethernet
