KAESER SIGMA CONTROL 2 User Manual

8.11.4.2 Set the time delay
The delay can be set between 0 and 600 seconds. The delay is counted down from 600 in 1
second increments with the «DOWN» key and counted upwards from 0 (zero) in 1 second
increments with the «UP» key.
1. Use «Up» or «Down» to select the td line.
2. Press «Enter».
The td delay time flashes.
8 8 p s i 0 8 : 1 5 A M 1 7 6 ° F
Header
5.7.4.1 System pressure pNloc
Menu
active: ☐
·········
SP: 7.2psi ¦ SD: −8.7psi
Switching point (SP) and switching differential (SD)
td: 0s ¦Logic +
Delay (td) and logic
DOR1.01 ☐
Output DOR
Operation ☐
Type of message
3. Use «Up» or «Down» to set the time delay in seconds.
4. Press «Enter».
Result The td delay time has been set.
8.11.4.3 Assign and activate the output
Once the threshold has been reached, you can switch a digital output DOR .
1. Use «Up» or «Down» to select the DOR line.
2. Press «Enter».
The DOR display flashes.
3. Select the output with the «Up» and «Down» keys.
4. Press «Enter».
The setting is applied.
8 8 p s i 0 8 : 1 5 A M 1 7 6 ° F
Header
5.7.4.1 System pressure pNloc
Menu
active: ☐
·········
SP: 7.2psi ¦ SD: −8.7psi
Switching point (SP) and switching differential (SD)
td: 0s ¦Logic +
Delay (td) and logic
DOR1.03 ok ☑
Output DOR
Operation ☐
Type of message
5. Press the «Right» key.
6. Press «Enter».
The check box assigned to the output flashes.
7. Press the «Up» key.
The check box is activated.
8 Initial Start-up
8.11 Setting input and output signals
No.: 9_9450 13 USE
User Manual Controller
SIGMA CONTROL 2 SCREW FLUID ≥5.1.2
165

KAESER SIGMA CONTROL 2 Specifications

General

Controller Type	Microprocessor-based
Model	SIGMA CONTROL 2
Manufacturer	KAESER
Input Voltage	24 V DC
Protection Class	IP54
Communication Protocols	Modbus, Profibus
Data Logging	Comprehensive data logging
Remote Monitoring	Yes
Communication Interface	Ethernet
