KAESER SIGMA CONTROL 2 User Manual

8. Press «Enter».
The output is assigned and activated.
ok is displayed.
8.11.4.4 Setting the message type
1. Select the message type line with the «Up» and «Down» keys.
2. Press «Enter».
The display for the message type flashes.
3. Use «Up» or «Down» to set the message type.
8 8 p s i 0 8 : 1 5 A M 1 7 6 ° F
Header
5.7.4.1 System pressure pNloc
Menu
active: ☐
·········
SP: 7.2psi ¦ SD: −8.7psi
Switching point (SP) and switching differential (SD)
td: 0s ¦Logic +
Delay (td) and logic
DOR1.03 ok ☑
Output DOR
Warning ☑
Type of message
4. Press «Enter».
5. Press the «Right» arrow.
6. Press «Enter».
The check box assigned to the message type flashes.
7. Press «Up» key.
The message is activated.
8. Press «Enter».
Result The message type is set and activated.
8.11.4.5 Activating the threshold
1. Use «Up» or «Down» to select the active: line.
2. Press «Enter».
The check box will flash.
8 8 p s i 0 8 : 1 5 A M 1 7 6 ° F
Header
5.7.4.1 System pressure pNloc
Menu
active: ☑
Active line with check box
·········
SP: 7.2psi ¦ SD: −8.7psi
Switching point (SP) and switching differential (SD)
td: 0s ¦Logic +
Delay (td) and logic
DOR1.03 ok ☑
Output DOR
Warning ☑
Type of message
3. Press the «Up» key.
The check box is activated.
8 Initial Start-up
8.11 Setting input and output signals
166
User Manual Controller
SIGMA CONTROL 2 SCREW FLUID ≥5.1.2 No.: 9_9450 13 USE

KAESER SIGMA CONTROL 2 Specifications

General

Controller Type	Microprocessor-based
Model	SIGMA CONTROL 2
Manufacturer	KAESER
Input Voltage	24 V DC
Protection Class	IP54
Communication Protocols	Modbus, Profibus
Data Logging	Comprehensive data logging
Remote Monitoring	Yes
Communication Interface	Ethernet
