Keysight N9915-90020 User’s Guide 105
NA (Network Analyzer) Mode
NA Mode Settings
The actual sweep time is shown on the FieldFox screen. See the Screen Tour
on
“Screen Tour” on page 44. To increase the sweep time, enter a value that is
higher than the actual sweep time. The increase will not be exactly the amount
that you enter, as the actual sweep time is the composite of many factors.
How to set Sweep Time
1. Press Sweep 3.
2. Then
Min Swp Time.
3. Enter a value using the numeric keypad.
4. Press a multiplier key. Learn about multiplier abbreviations in
“Multiplier
Abbreviations” on page 46.
Triggering (NA)
External triggering (NA and SA modes ONLY) allows you to initiate a sweep
when an external DC voltage is sensed at the Ref In/Trig In connector on the
FieldFox top panel. See External Triggering for SA Mode in
“Triggering” on
page 197
.
Trigger Source
1. Press Sweep 3
> Trigger > Trig Source
2. Then choose from the following:
— Int (Internal) Sweeps are initiated by the FieldFox internal circuitry.
When Sweep is set to Continuous, a new sweep begins
automatically when the previous sweep ends.
— Ext (External) A sweep is initiated on the rising or falling edge of an
external TTL signal at the Ref In/Trig In connector on the FieldFox
top panel.
— When the FieldFox is armed for an external trigger signal,
Wait is annotated on the display.
— A sweep can NOT be initiated by an external signal while a
sweep is in progress.
— A sweep can NOT be initiated by an external signal when in
HOLD mode. Learn more about HOLD mode in.
Measurement speed specifications do NOT apply in Temperature Control
Mode. Learn more in
“Temperature Control Mode” on page 33.
