Keysight Technologies C Series - How to make Time Domain Gating settings; Start, Stop, Center, and Span Gate Times; Gating Type

Keysight N9915-90020 User’s Guide 123
Time Domain – Option 010
Gating
Trace 4 shows the frequency response with gating enabled.
How to make Time Domain Gating settings
—Press Measure Setup 4
—Then Transform
—Then Gating
— Then choose from:
— On Gating is being performed.
—
Off Gating is NOT being performed.
Start, Stop, Center, and Span Gate Times
These settings specify the time in the trace to be gated (in or out). The gate
times can be specified using either Start and Stop or Center and Span.
—Press
Gating Start Stop
— A settings table appears that allows you to navigate and select the
following settings. These settings are made exactly like those made on the
Transform Settings table. Learn how in
“Transform Settings Table” on
page 116.
Gating Type
This setting defines the type of filtering that will be performed for the gating
function. The gate start and stop flags on the display point toward the part of
the trace you want to keep.
Choose from the following:
—
Bandpass KEEPS the responses within the Gating Start and Stop times.
—
Notch REMOVES the responses within the Gating Start and Stop times.
