Keysight Handheld Analyzers
N99xxC User’s Guide - Option 360 Phased Array Antenna
14 5G Rapid Prototype Phased Array Antenna – Option 360
Option 360 measures signals at the SA RF Input Port 2 connector.
Option 360 requires the FieldFox to have SA mode (Option 233 on combination
analyzers), and GPS (Option 307) installed.
Recommended, but not required, preamplifier (Option 235) to improve receiver
sensitivity.
Keysight's FieldFox handheld analyzer (with Option 360) combined with a Ball
Aerospace / Anokiwave 64-element antenna array provides a unique, portable
solution for measuring and analyzing the 5G air interface in the field.
— Reduce measurement complexity with integrated RF probe and phased
array solution to capture energy radiated from gNB
— Calibrated metrology milli-meter wave phased array antenna simulates 5G
UE antenna performance
— Troubleshoot the 5G radio access network with 3D test coverage and path
loss measurements utilizing the built-in CW generator
— Phased array performance verification showing bore sight, polar antenna
pattern with compass, heat map and beam sweep to map display views
IMPORTANT!
85571A-028 (28 GHz 5G Phased Array Antenna) accessories not suitable
for use in wet locations.
PAA mode is compatible with the frequency converter heads, but cannot
apply or edit the frequency head corrections. Refer to
“Utilities” on
page 772
.
Learn more, refer to
https://www.keysight.com/us/en/assets/9018-04847/user-manuals/901
8-04847.pdf (N9938-90005).
The FieldFox can be used with an OML frequency extender. Refer to
“Utilities” on page 772, the Configuration Guide at:
https://www.keysight.com/us/en/assets/7018-06515/configuration-guid
es/5992-3701.pdf
(5992-3701EN), and to “Contacting Keysight” on
page 5.
