Keysight N9915-90015 User’s Guide 467
USB Antennas – (Full Capability Requires EMF Option 358, and either SA mode (Option
233 Mixed Analyzers) or OTA—5G NR / 5G NR EVM Conducted Option 378)
How to Set Up a USB Antenna (Also, Known as EMF Antenna)
How to Set Up a USB Antenna (Also, Known as EMF Antenna)
This section reviews some general high level steps in setting up a USB antenna
measurement. If you are not familiar with this process or would like more
information on specific EMF measurement setups, refer to:
— SA Mode:
“How to Set Up EMF Settings (Requires EMF (Option 358), GPS
(Option 307), and SA Mode (Option 233–Mixed Analyzers))” on page 230
—OTA Mode: “How to Set Up EMF Mode Settings (Requires EMF (Option
358) and 5G NR (Option 378))” on page 400
USB Antenna Setup Procedure
1. Select the mode and set up your measurement. Refer to Chapter 13,
“Over–the–Air Measurements (OTA) – LTE FDD Option 370, LTE TDD Option
371, 5G TF Option 377, 5G NR / 5G NR EVM Conducted Option 378”
or to
Chapter 9, “SA (Spectrum Analyzer) Mode (Option 233–Mixed
Analyzers)FUTURE”
.
2. Connect a USB antenna. Refer to
Figure 15-1.
3. Importing and selecting the X/Y/Z antenna factors:
a. OTA – 5G NR and SA Mode:
Press System
> Utilities > EMF Antennas >
IMPORTANT! See also, “Alignments” on page 206, in NA mode,Chapter 9,
“SA (Spectrum Analyzer) Mode (Option 233–Mixed Analyzers)FUTURE.”
If necessary, this step can be skipped and done after the USB antenna is
set up.
Only Agos Advanced Technologies SDIA–6000 Triaxial Lsotropic USB
antenna is compatible with EMF (Option 358). See also Chapter 9, “SA
(Spectrum Analyzer) Mode (Option 233–Mixed Analyzers)FUTURE”
and
Chapter 13, “Over–the–Air Measurements (OTA) – LTE FDD Option 370, LTE
TDD Option 371, 5G TF Option 377, 5G NR / 5G NR EVM Conducted Option
378”
.
