110 Keysight N9915-90020 User’s Guide
NA (Network Analyzer) Mode
NA Mode Settings
You can also set Velocity Factor by pressing Meas Setup 4 then
Calibration (Settings).
Big Marker Display States (A and B)
This feature, available ONLY in NA Mode, allows you to view up to three Big or
Super Big marker readouts. This is done by using up to two different display
states called A and B. Each display state is comprised of the settings listed
below. When the Big Readout setting is toggled through A and B, these display
states are recalled.
How to create Big Marker Display States
To have big readouts, markers MUST be created using the following procedure.
If you have already set up your display and do not want to lose it, then save the
current state to a state file. Learn how in “State Files” on page 822. The
following procedure will overwrite your display state.
—Press Mkr ->/ Tools
—Then Big Readout
—A or B - The A or B display state is recalled. If none have been defined,
then the default display state is recalled.
—OFF - The B display state is visible but without the Big Marker
Readout.
— With A or B selected, then press
Edit Big Marker (A or B)
— Then edit the following display state settings:
— Num Traces – Choose the Multi-Trace configuration x1, x2, or x3. Only
Overlayed configurations are allowed. Learn more in “Multi-Trace
Configurations” on page 95.
— Font Size – Choose either Big or Super Big. Super Big marker readout #3
will cover some of the measurement grid.
— Trace Settings - For each possible trace (1, 2, and 3) select from the
following:
—Measurement – S-parameter or Receiver measurement to display.
S11 is default. Learn more in
“About S-parameters” on page 91.
—Meas Format – Log is default. Learn more in
“Format” on page 98.
— Bandwidth (ON) – Marker readout for marker bandwidth search.
OFF is default. Learn how to set BW parameters in
“How to Search
with Markers” on page 740
.
— Big Readout - For each marker readout (1, 2, and 3), select from the
following:
—Marker # - Enter a number from 1 to 6 to create the marker. 1 is
created by default.
