650 Keysight N9915-90020 User’s Guide
Channel Scanner (Option 312)
How to Set Up Channel Scanner
— Save Image (PNG) Saves the current displayed map to a
*.png file (default filename is “MapImageFile”).
7. Outdoor Mapping: Export KML file into 3rd party mapping software (i.e.,
Google or Google Earth)
Learn more, refer to
Chapter 16 Mapping and “Setting up Data Logging” on
page 503
. See also, Chapter 33, “File Management.”
How to Define a Channel and Use Channel Scanner
Channel definitions consist of the following:
— Each channel is defined by CF and Integration BW.
— Frequency span is set automatically to 1.5 x Integration BW
— Power is measured over the Integration BW
Using Channel Scanner, refer to:
—
“Step 1A: Scan Mode: Range Channel Defined” on page 651 or
—
“Step 1B: Scan Mode: Custom List Channel Defined” on page 652
Then:
—
“Step 2: Select Display Type” on page 653
— “Step 3. Modify Scale and the Display Color Bar Settings” on page 657
— “Step 4: Enable Data Logging and Play Results” on page 658
— “Step 5: Save the Log Results:” on page 661
— “Step 6: Import and Play back KML Files into 3rd Party Software (Example:
Google Earth with Animation Tool)” on page 663
Data Log-Play files are saved to:
— If File Folder is set to Default then Data Log-Play files are save-recalled to:
"[CurrentDevice]\RecordPlayback\CS"
— If File Folders are set to System, then Data Log-Play files are save-recalled
to: "CurrentDevice\<UserSelectedFolder>\
