Keysight N9915-90020 User’s Guide 663
Channel Scanner (Option 312)
How to Set Up Channel Scanner
7. When done press Back or Esc. The files save dialog is displayed. Edit the
file name where the file results will be stored as a *.kdat file.
8. Press Done
Learn more, refer to Chapter 16 Mapping and “Setting up Data Logging” on
page 503. See also, Chapter 33, “File Management.”
Step 6: Import and Play back KML Files into 3rd Party Software
(Example: Google Earth with Animation Tool)
Features
Use the Playback Slider to replay measurement results. See also Google Maps
and or Google Earth’s help.
— Open the FieldFox *.KML file in Google Earth. Time Slider appears in upper
left of the map.
— Manual Mode – Move the time slider cursor to see color-coded icons
pop-up according to the timestamp.
— Loop mode has a Fast-Slow Replay Option.
— Click on each color coded balloon to see the table of measurement results
for that location.
Figure 28-14 Importing a KML File Into Google Earth
