280 Keysight N9915-90020 User’s Guide
RTSA (Real-time Spectrum Analyzer) Mode—Option 350
RTSA Mode Settings
Audio Beep at Marker Power
When enabled, the Audio Beep feature emits a repetitive beep sound which
varies in tone pitch and repetition rate to indicate the relative power level of the
active marker. The highest tone pitch and fastest beep rate occurs when the
marker Y-axis position is at the top of the display. Conversely, the lowest pitch
and repetition rate occurs at the bottom of the display. Therefore, it is
important to scale the signals that you intend to measure between the top and
bottom of the screen. Learn more about Scale in
“Scale and Units” on
page 261
.
Audio Beep can be used with any marker type or function, including
Band/Interval Power. Learn more in “Audio” on page 786.
How to use Audio Beep
1. Press Marker
2. Optionally, press Marker 1 2 3 4 5 6 to select an existing marker to use
with Audio Beep. A marker will be created if one does not already exist.
3. Then More > Audio Beep ON OFF
Audio Beep does NOT beep when the FieldFox is in Hold mode.
While Audio Beep is ON, press
Marker 1 2 3 4 5 6 to toggle Audio Beep
through the existing markers.
To set FieldFox speaker volume control, press System, then Volume. Learn
more in
“Audio” on page 786.
