Keysight N9915-90020 User’s Guide 511
Indoor and Outdoor Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option
233), and GPS Receiver (Option 307))
How to Use Data Logging (Option 352)
How to Use Data Logging (Option 352)
Data Logging enables you to use GPS mapping data and play them back at a
later time. Use this feature to overlay Maps pointers on your indoor or outdoor
files.
Data logs can be saved to the FieldFox Internal memory, an SD Card, or a USB
flash drive.
This section assumes you have already completed the initial setup and have a
measurement setup in the FieldFox.
This section contains the following sections:
—
“Screen Annotation” on page 511
— “How to Add Directional Finding (DF) Bearing” on page 513
— “How to Record a Data Log (Outdoor Logging Only)” on page 516
— “To change Data Logging Configuration settings:” on page 517
— “How to Play a Data Log” on page 517
Screen Annotation
During a record or playback session, the following is displayed in the
top-center area of the screen:
—
Rec: 55/55 2018-12-31 03:26:11 PM
where:
—
55/55 is the current and total trace number: currently trace is 55 of 55 total
scans.
— 2018-12-3103:26:11 PM is the date and time of recording.
— The name of a recording can be changed using Manage Sessions. Learn
more in
“To change Data Logging Configuration settings:” on page 517.
See also, the FieldFox User’s Guide’s Settings” chapter.
When GPS is enabled, GPS R
is indicated at the bottom of the FieldFox
display. Learn more, see the FieldFox User’s Guide’s “System Settings”
chapter.
The Mapping mode can display and be data logging can be recorded/played
back in field strength units (Option 360 only), when the units are changed:
Data Log-Play files are saved to:
— If File Folder is set to Default then Record-Play files are save-recalled
to:
"[CurrentDevice]\RecordPlayback\[Current mode]\"
—
If File Folders are set to System, then Record-Play files are
save-recalled to: "CurrentDevice\<UserSelectedFolder>\"
