Keysight N9915-90020 User’s Guide 203
SA (Spectrum Analyzer) Mode (Option 233–Mixed Analyzers)FUTURE
SA Mode Settings
Single / Continuous / Restart
This setting determines whether the FieldFox measures continuously or only
once each time the
Single or Run / Hold +/- button is pressed. Use Hold /
Single or to conserve battery power or to allow you to save or analyze a
specific trace.
How to set Single or Continuous
1. Press Sweep 3
.
2. Then choose one of the following:
—
Continuous
— ON Causes the SA to make continuous sweeps. This is the
typical setting for making measurements. Each Run / Hold
+/- press causes the SA to toggle between continuous
sweep and Hold.
— OFF Causes the SA to Hold. Each Run / Hold +/- or Single
press causes the SA to make ONE sweep, then Hold. The
Hold annotation changes to an arrow --> while the sweep
occurs.
—
Single Automatically sets Continuous OFF and causes the SA to
make ONE sweep, then Hold.
— Restart Resets the Average counter to 1. The Average counter also
is used with MaxHold and MinHold Trace States. Learn more in
“Average Count” on page 205.
Points
Points is the number of measurements that are displayed along the X-axis. The
higher number of data points, the better the ability to resolve closely spaced
signals and the slower the sweep speed.
How to set number of points
1. Press Sweep 3
> Points [current setting]
2. Then choose from:
— 101 | 201 | 401 | 601 | 801 | 1001
— # Points to enter a trace points value manually (Maximum = 20001).
Trace Display States (SA Mode)
— In SA Mode you can display up to four of the following types of trace states.
All SA settings are applied to all displayed traces.
See also “Marker Trace
(IQA and SA Mode)” on page 738
.
