Keysight Technologies C Series - Trace Memory

608 Keysight N9915-90020 User’s Guide
Pulse Measurements Mode – Option 330
Pulse Measurement Settings
—Then Grid
— OFF Grid OFF
—
ON A grid of X/Y lines appears on the screen.
Trace Memory
A memory trace is a pulse measurement Tr 1 data trace (NOT the trace in the
Zoom window) that has been stored in the FieldFox volatile memory. It then
becomes static, meaning it is not updated with normal pulse measurements. It
can be displayed on the screen by itself, or with a pulse trace for comparison
purposes.
The Tr 1 data trace is displayed in yellow.
The memory trace is displayed in blue.
How to display data and memory traces
—Press Trace 6
.
—Then
Trace Memory
—Then
Data->Mem to store the current live trace into memory. A ‘beep’
sounds to confirm the data trace has been saved to memory. There is no
display annotation that indicates that the memory trace has been stored.
—Press
Data to view only the data trace.
—Press
Memory to view only the memory trace.
—Press
Data & Memory to view both the live trace and the stored
memory trace.
