How to Use Data Logging/Playback (Option 360)
—Then Record Save/Recall
—Then Device (Internal (default), SD Card, or USB)
—Then
File Type (CSV, DREC (Option 360 only), or KML (default))
Learn more, refer to the
Chapter 33, “File Management”.
How to Playback a Data Log
—Press Trace 6
— If the session is already open, skip the following step. Otherwise:
—Then
Data Logging > Record Save/Recall
—Then Recall Log File use the Use the RPG or the arrow keys to
highlight the file to be played.
——Then
Recall File
——Then
Back
—Then Play to playback your Table data.
is displayed in the left of screen graticules during playback. When the
end of the recording is reached, playback begins at the start of scan and
continues to loop indefinitely.
During playback, choose from the following:
—
Pause Resume
Temporarily halts playback. Then choose from the following:
— Pause Resume
Press to continue playing.
—
Stop
Immediately stops playback. Then choose from the following:
— Play Start playback from start of scan.
—
Recall Log File
Opens a list of stored data files.
Select a file to playback.
—
Recall File
—
Back
—
Cursor Position
use this softkey to move the data log play cursor in the
current data log being played (i.e., Cursor Position is active only when
playback is paused).
If these are large recordings on a device, it could take several seconds for
the FieldFox to display the list.
