Keysight Handheld Analyzers
N99xxC User’s Guide
5 TDR (Time Domain Reflectometry) - Option 215
CAT Mode Time Domain Reflectometry (TDR) measurements are generally
used to locate problems, and identify the type of problem, in a length of cable
or transmission line.
Settings that are NOT unique to TDR measurements are documented in
Chapter 3, “CAT (Cable and Antenna Test) Mode”, on page 49.
In this chapter, the cable to be tested is referred to as the DUT (Device Under
Test).
In this Chapter
“TDR Measurement (Format)” on page 78
“TDR Settings Table” on page 78
“TDR Start and Stop Distance” on page 79
“TDR Sweep” on page 79
