Keysight Technologies C Series - Option 352 Outdoor Maps Setup Procedure

Keysight N9915-90020 User’s Guide 495
Indoor and Outdoor Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option
233), and GPS Receiver (Option 307))
How to Set Up Mapping Settings
Option 352 Outdoor Maps Setup Procedure
Outdoor mapping requires GPS Option 307.
1. Set up your measurements in Channel Scanner, OTA, or Phased Array
Antenna. See also,
Chapter 13, “Over–the–Air Measurements (OTA) – LTE
FDD Option 370, LTE TDD Option 371, 5G TF Option 377, 5G NR / 5G NR
EVM Conducted Option 378,” and Chapter 28, “Channel Scanner (Option
312).”
One or more are required:
— For setting up GPS Option 307, refer to Chapter 31, “System
Settings,”
and then “GNSS (GPS+) and GPS” on page 795.
— For setting up a phased array antenna, refer to
Chapter 14, “5G
Rapid Prototype Phased Array Antenna – Option 360.”
— For setting up a USB antenna, refer to Chapter 15, “USB Antennas –
(Full Capability Requires EMF Option 358, and either SA mode
(Option 233 Mixed Analyzers) or OTA—5G NR / 5G NR EVM
Conducted Option 378).”
2. Plan the area you want to map with GPS Option 307 enabled.
a. Optional (Can be done later): Save mapping pictures to the FieldFox
using USB storage device, SD card, or connect to LAN with internet
and download. Refer to “How to Install Node.js and Running the
FieldFox Mapping Software” on page 478. For FTP, refer to :MMEM
SCPI in the FieldFox Programming Help
https://www.keysight.com/us/en/lib/resources/service-manuals/k
eysight-fieldfox-library-help-and-manuals-2153870.html (via
Keysight FieldFox Library, Help and Manuals (near bottom of page).
b. Optional (Can be done later):
IMPORTANT!
85571A-028 (28 GHz 5G Phased Array Antenna) accessories not suitable
for use in wet locations.
Saving and importing maps can be done now or after the outdoor map
locations have been measured. Before you can save and import maps via
the internet, your PC requires the FieldFoxMapping software. Refer to
“How to Install Node.js and Running the FieldFox Mapping Software” on
page 478
.
Saving and importing maps can be done now or after the outdoor map
locations have been measured. Refer to
“How to Install Node.js and
Running the FieldFox Mapping Software” on page 478
.
