Channel Scanner (Option 312)
How to Set Up Channel Scanner
How to Set Up Channel Scanner
This section briefly reviews the steps in setting up a channel scan
measurement. If you are not familiar with this process or would like more
information, refer to
“How to Define a Channel and Use Channel Scanner”.
1. Define some channels (refer to “How to Define a Channel and Use Channel
Scanner”
).
a. Select a Scan Mode—choose:
— Range Specify total channels, channel spacing or
—
Custom List Specify a list of channels from an editor
b. Then modify channels based on the selected scan mode
2. Select
Display Type
—choose:
— Bar ChartV or
— Bar ChartH or
— Channel Pow or
— Strip Chart or
— Then
More and
— Chart Overlay or
—
Scan&Listen
3. Modify scale and specify color bar coding—Modify the scale and assign
colors to low and high power channels (bars):
Press Scale/Amptd
Then one of the following:
— Red Limit to set the power level and color scale for high power
channels.
— Blue Limit to set the power level and color scale for low power
channels.
— Others: Scale, Ref Level, RF Atten, etcetera as desired.
4. Enable Data Logging Settings: Press Measure 1
or Trace 6 > Data Logging
to view the Data Logging softkeys and set the
Record Settings, Record
Save/Recall, and More > Indoor Map Data Logging or Signal Locate.
— Record (Outdoor Logging) or
— Play (If you have previously stored data recordings.) or
— View
a. To set the
Record Settings
(Outdoor Mapping only)—choose:
