286 Keysight N9915-90020 User’s Guide
RTSA (Real-time Spectrum Analyzer) Mode—Option 350
Record/Playback (RTSA Option)
In addition, you can insert a ‘User Tag’ at any time during a recording session
to indicate an external event, such as when an antenna is moved. During
playback, you can move quickly to any of these tags, or scroll through these
tags.
A symbol is used on the screen annotation to distinguish a User Tag from a
State Tag when scrolling through tags during playback.
Screen Annotation
During a record or playback session, the following is displayed in the top-left
area of the screen:
—
AutoSession02: 92/95 (state 4/5)_*_
Sep.22.2018 09:15:15 AM
where:
—
AutoSession is an auto-generated name for sessions. 02 is the
auto-generated number, incremented with each new session. The name
can be changed using Manage Sessions. Learn more in
“Manage Sessions”
on page 290
.
—
92/95 is the current and total trace number: currently trace is 92 of 95 total
traces.
— state 4/5 is the current and total state tag or user tag number: 4 of 5 total
tags.
— * (Asterisk) indicates that a state has changed. # (Pound) indicates that a
User Tag has been inserted.
— Sep.22... is the date and time of recording.
When GPS is enabled`, the current location and elevation are annotated at the
bottom of the playback display. Learn more in
“GPS – Distance Settings” on
page 787
.
How to Record a Session
1. Press Trace 6 > Record Playback
2. Then either:
— New Session OR
If Recording or Playback is not occurring when you think it should, check
the following:
— Is the sweep in HOLD? (upper-left annotation), or check the Sweep
menu for Continuous set to OFF.
— Is Recording or Playback Paused? (mid-left annotation)
— Is the Record or Playback Interval set too long? (Configuration
settings.)
