All about Trace Math
Keysight N9915-90020 User’s Guide 761
All about Trace Math
Trace Math is available in CAT (excluding DTF measurements), NA Mode, and FOPS (under USB
Power Meter mode).
A trace is a series of measurement data points that are connected to form a line. This ‘live’ data
trace is updated as data points are measured.
A memory trace is a live trace that has been stored in the FieldFox volatile memory. It then becomes
static, meaning it is not updated with measurements. It can be displayed on the screen by itself, or
with a data trace for comparison purposes.
— In NA mode, memory traces are the same color as data).
— In CAT mode and FOPS, the data trace is displayed in yellow and the memory trace is displayed
in blue.
How to display data and memory traces
1. Press Trace 6.
2. Press
Math and Memory then Data->Mem to store the current live trace into memory. A ‘beep’
sounds to confirm the data trace has been saved to memory. There is no display annotation
that indicates that the memory trace has been stored.
3. Then choose from:
— Press
Data to view only the data trace.
— Press
Memory to view only the memory trace.
— Press
Data & Memory to view both the live trace and the stored memory trace.
How to perform Trace Math
Trace math is performed between a live trace and a memory trace. When one of the following math
operations are selected, the yellow data trace displays the current measurement with the selected
trace math applied. The math operation symbol indicated below in [brackets] is displayed on the
lower left corner of the screen.
1. Press Trace 6
.
2. If not already stored, press
Data->Mem to store the current live trace into memory.
3. Then
Data Math.
4. Then choose one of the following:
—
Data + Mem [D+M] Current measurement data is added to the data in memory.
Noise Figure (NF—Option 356) does not have trace math, but does have
the ability to display data and memory traces. Refer to
“How to display
data and memory traces”
.
