Data Analysis FeaturesDELETE_IF
All about Markers
748 Keysight N9915-90020 User’s Guide
The following applies to DTF Measurements ONLY:
— More then:
—
Mkr->Start Distance The Start Distance of the measurement becomes the value of the
active marker. Markers that would no longer appear on the screen are moved to the new
Start Distance.
—
Mkr->Stop Distance The Stop Distance of the measurement becomes the value of the
active marker. Markers that would no longer appear on the screen are moved to the new
Stop Distance.
I/Q Analyzer (IQA) Marker Functions
The following Marker Functions are available in I/Q Analyzer Mode ONLY (exceptions are noted):
— Noise Marker (Available in SA mode)
— Band/Interval Power Marker (Available in SA mode)
— Coupled Markers
— Band Span
— Interval Band Span
—Continuous Peak Search
Learn more about Noise and Band/Interval Power marker functions starting in the IQA chapter here:
“Noise Marker” on page 314.
SA Marker Functions
The following Marker Functions are available in SA Mode ONLY (exceptions are noted):
— Noise Marker (Available in I/Q Analyzer mode)
— Band/Interval Power Marker (Available in I/Q Analyzer mode)
— Frequency Counter at Marker
— Audio Beep with Marker
— Time Zero Fixed Marker
Learn more about these marker functions starting in the SA chapter here:
“Noise Marker” on
page 215
.
