3 CAT (Cable and Antenna Test) Mode
In this Chapter
CAT Mode is typically used to test an entire
transmission system, from the transmitter to the
antenna. This process is sometimes referred to as
Line Sweeping.
CAT Mode is similar to NA (Network Analyzer)
Mode. Learn more in the Supplemental Online Help:
https://rfmw.em.keysight.com/wireless/helpfiles/Fi
eldFoxOnlineSupplementalHelp/Home.htm
.
CAT Mode Distance to Fault measurements are
discussed in
Chapter 4, “DTF (Distance to Fault)
Measurements.”
.
IMPORTANT! For CAT and NA modes, limit lines do not apply
where F1 = F2.
“Measurement Selection” on page 51
“Quick Settings Table” on page 52
“Frequency Range” on page 53
“Scale Settings” on page 53
“Averaging” on page 54
“Smoothing” on page 55
“Single or Continuous Measure” on page 55
“Resolution (Number of Data Points)” on page 56
“Sweep Time” on page 56
“Output Power” on page 57
“Interference Rejection” on page 58
“Coupled Frequency” on page 58
