646 Keysight N9915-90020 User’s Guide
Channel Scanner (Option 312)
Using Channel Scanner
Using Channel Scanner
Channel Scanner enables you to do the following:
Figure 28-1 Display Example: Measure 5 Channels Spaced 2 MHz Apart
Measure and display channel power vs. frequency for up to 20 channels simultaneously.
Six Display Types:
— Bar graph vertical display orientation
— Bar graph horizontal display
orientation
— Channel Power
—Strip Chart
— Strip Chart and Overlay
—Scan & Listen
Color Coded Display Types:
— Specify high and low power with
color bars
Flexible Data Sorting:
— Sort results displayed by power or
frequency, low to high, or high to low
Data Logging GPS stamped data measurements
— Define measurement interval by time
or distance
— Show results in spectrogram
— Replay files on Google Maps or
Google Earth
— Manual directional mapping
