Keysight Technologies C Series - Using EMI Measurements (Option 361)

Keysight N9915-90020 User’s Guide 327
Electromagnetic Interference (EMI) Measurements – Option 361
Using EMI Measurements (Option 361)
Using EMI Measurements (Option 361)
EMI enables you to do the following:
Measure and display emission signals to verify your device/instrument’s pre-compliance
performance
Electromagnetic Interference Features (EMI) – (Option 361)
— Amplitude Probability Distribution (APD)
Statistics, both CCDF and Histogram
— Selectable CISPR bands (A, B, C, D,
E)
— Fast SA Scan for quick setup check
— Frequency range coupled to CISPR bands
— Logarithmic frequency axis
— 200 Hz, 9 kHz, 120 kHz 6 dB resolution
bandwidths, and 1 MHz impulse
bandwidth, auto–coupled to CISPR bands
— EMI Detector settings, selectable per
trace
— Quasi-Peak
—EMI Average
— Positive Peak
— Simple Color coded Trace/Detector
pair controls
