468 Keysight N9915-90015 User’s Guide
USB Antennas – (Full Capability Requires EMF Option 358, and either SA mode (Option
233 Mixed Analyzers) or OTA—5G NR / 5G NR EVM Conducted Option 378)
How to Set Up a USB Antenna (Also, Known as EMF Antenna)
— Then Import Antenna – to import the antenna factors from the USB
antenna connected to the FieldFox.
— Then Antenna Select [Tri Axial] verify Tri Axial is selected (Default
== Manual). Only compatible USB triaxial antennas can be used for
EMF measurements.
— Optional: Press
Antenna Axis with Auto (default) selected the
FieldFox determines the X/Y/Z settings for the current
measurement. Alternately, you can select either X, Y, or Z to enable
and to edit a position manually (i.e., an example of editing X, Y, and
Z axes is covered in step
5).
4. If you have not selected a mode and set up your measurement, then do so
now. Refer to step
1.
5. Enabling the imported USB antenna factors and Cable factors:
Choose one of these:
— SA Mode:
“How to Set Up EMF Settings (Requires EMF (Option 358),
GPS (Option 307), and SA Mode (Option 233–Mixed Analyzers))” on
page 230
.
— OTA Mode:
“How to Set Up EMF Mode Settings (Requires EMF
(Option 358) and 5G NR (Option 378))” on page 400
.
6. If you need to edit or add new antenna factors or cable factors, then
repeat step
5 as required for Y, Z, and the Cable Factors. See also, “How to
Set Up EMF Settings (Requires EMF (Option 358), GPS (Option 307), and
SA Mode (Option 233–Mixed Analyzers))” on page 230 and “How to Set Up
EMF Mode Settings (Requires EMF (Option 358) and 5G NR (Option 378))”
on page 400
.
7. Once you have finished with your USB antenna setup:
a. Press Sweep 3
> Single > Restart
The FieldFox should display in order Analyzing CCO X-Axis,
Analyzing CCO Y-Axis, and Analyzing CCO X-Axis and then
do a square root sum of the X, Y, and Z measurement values in the
FieldFox. Multi-cell measurements are done similarly for each cell
ID (i.e., Cell CC0 to CCn). Refer to
Figure 15-4 on page 469.
If the antenna factor import is successful, the FieldFox displays:
"Success: Antenna Factors Imported: Tri-Ax Antenna ID:
->[R] Antenna ID: SDIA-6000-1006 ->[]". The last 4-digits will vary
for each antenna (i.e., “1006” is changeable).
If the FieldFox displays this error Error: USB antenna Error: Not
found or Unable to communicate with antenna. Ensure it is
connected. is displayed, verify the USB antenna is connected correctly.
Refer to
“Troubleshooting” on page 472.
