168 Keysight N9915-90020 User’s Guide
SA (Spectrum Analyzer) Mode (Option 233–Mixed Analyzers)FUTURE
SA Mode Settings
1. Press Done to close the Antenna/Cable Editor.
2. Press
Antenna Off On > On.
Then choose your final measurement amplitude unit, under Scale/more. If
you selected either
dB /m or dB S/m for the Antenna Factor unit, you
should see this list of available Field Strength units
3. Press Scale/Amptd
> More > Unit dBuV/m and choose from:
—
dBµV/m == dB micro Volts per meter
—
dBm/m^2 == dBm per meter squared
—
V/m == volts per meter
—
W/cm^2 == watts per cm squared
—
W/m^2 == watts per meter squared
—
dBµA/m == dB micro Amps per meter
—
dBG == dB gauss
—
dBpT == dB pico tesla
4. Press
Back > Back > Save Antenna or Save Cable to save your changes to
the specified Storage Device. Enter a filename using the FieldFox labeler
(learn more in “How to use the FieldFox labeler ” on page 820). Learn more
about Antenna and Cable files below.
Optional:
—Press
Recall Antenna or Recall Cable to load an Antenna or Cable file from
the specified Storage Device.
— Storage Device Changes the device used to save or recall files. Choose
from Internal (default setting), USB (must be connected) or SD card. This is
a different setting from the Save/Recall Storage Device setting.
About Antenna and Cable files
— Cable files are saved and recalled from the Cables folder.
— Antenna files are saved and recalled from the Antenna folder.
—To DELETE Cable or Antenna files, use the Manage Files feature. Learn more
in
“Manage Files” on page 826.
— If the folder does not already exist on a USB or SD card, it is created
automatically before storing the file.
— All Antenna and Cable files are saved and recalled as *.csv files, which
allows them to also be read by spreadsheet programs.
