Keysight N9915-90020 User’s Guide 377
Over–the–Air Measurements (OTA) – LTE FDD Option 370, LTE TDD Option 371, 5G TF
Option 377, 5G NR / 5G NR EVM Conducted Option 378
How to Set Up Over–the–Air (OTA) Mode Settings
— Then Back
b. Then press Record Save/Recall To set file settings choose
— Save Log File to save the current Table data (i.e., default save
device is Internal). i.e., *.KML or *.CSV (default) files are saved
to the file name and device type. See Settings below and
“To
change Data Logging Configuration settings:” on page 409
— Recall Log File select a filename from the list
—
File Folder
Default - selects [Internal]:RecordPlayback\OTA
(default) or System - selects [Internal] top of internal
directory.
—
Device
choose where to store your data files
—
File Type > CSV or KML choose a file type (Default: CSV)
—
Auto Save OFF (default)/ON. When enabled, a temporary log
file (e.g. TempAutoSave.csv) is automatically saved after
each new record is recorded to guard against data lose in the
case of an unexpected shutdown. The temporary log file is
automatically deleted after you stop recording and manually
save the log file.
or
— Back
c. Indoor Map Data Logging - then Record Indoor Data or Recall
Indoor Log File.
— Then choose Navigate OFF ON, Data Selection, Zoom, Pan,
Record Data, More
Learn more, refer to Chapter 16 Mapping and “Setting up Data Logging”
on page 503
. See also, Chapter 33, “File Management.”
13. Outdoor Mapping only: If recording, then:
— View Map OFF ON To enable/disable the current map view (default
= latitude/longitude = 0.00/00. Need GPS to view current location
(default = OFF).
—
Pause Resume Temporarily halts recording until pressed again. The
incoming trace continues to sweep. Press again to continue
recording.
Learn more about file settings, refer to
Chapter 33, “File Management.”
