398 Keysight N9915-90020 User’s Guide
Over–the–Air Measurements (OTA) – LTE FDD Option 370, LTE TDD Option 371, 5G TF
Option 377, 5G NR / 5G NR EVM Conducted Option 378
How to Set Up Over–the–Air (OTA) Mode Settings
Procedure:
1. Press When done press
Stop. Immediately stops recording and a “Save
the Log File” menu opens to rename and save your data log file.
2. In the “Save the log file” window that opens, optionally change the name
of the default file displayed, else press
Done.
Saves the file and exits the current softkey menu.
3. ‘To begin recording: Press
Record
4. When done press
Stop. The file is automatically saved to the defined
Device Type and File Type.
Else, edit the file name and folder path, under Record Save/Recall > File
Folder where the file results will be stored.
5. Press Back
Learn more, refer to
Chapter 16 Mapping and “Setting up Data Logging” on
page 503
.
Step 6: Import and Play back KML Files into 3rd Party Software
(Example: Google Earth with Animation Tool)
Features
Use the Playback Slider to replay measurement results. See also Google Maps
and or Google Earth’s help.
— Open the FieldFox *.KML file in Google Earth. Time Slider appears in upper
left of the map.
— Manual Mode – Move the time slider cursor to see color-coded icons
pop-up according to the timestamp.
— Loop mode has a Fast-Slow Replay Option.
Record-Play files are saved to:
— If File Folder is set to Default then Record-Play files are
save-recalled to: "[CurrentDevice]\RecordPlayback\[Current
mode]\"
— If File Folders are set to System, then Record-Play files are
save-recalled to:
"CurrentDevice\<UserSelectedFolder>\
Learn more about file settings, refer to Chapter 33, “File Management.”
