456 Keysight N9915-90020 User’s Guide
5G Rapid Prototype Phased Array Antenna – Option 360
How to Use Data Logging/Playback (Option 360)
Figure 15-18 Field Strength Annotation that can be Logged and Played Back
If Data Logging or Playback is not occurring when you think it should,
check the following:
— Is the sweep in HOLD? (upper-left annotation), or check the Sweep
menu for Continuous set to OFF.
— Is Recording or Playback Paused? (mid-left annotation)
— Is the Data Logging or Playback Interval set too long? (Configuration
settings.)
