492 Keysight N9915-90020 User’s Guide
Indoor and Outdoor Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option
233), and GPS Receiver (Option 307))
How to Set Up Mapping Settings
3. If you are using an antenna with your measurements, then Connect your
equipment similar to
Figure 14-1 on page 425 in Chapter 14, “5G Rapid
Prototype Phased Array Antenna – Option 360” or to Figure 15-1 on
page 462
in Chapter 15, “USB Antennas – (Full Capability Requires EMF
Option 358, and either SA mode (Option 233 Mixed Analyzers) or OTA—5G
NR / 5G NR EVM Conducted Option 378)”
.
4. Then press Esc > Back > Measure 1 or Trace 6 > More (required for OTA
only) > Data Logging
to view the Data Logging softkeys and set the Record
Settings, Record Save/Recall, and More > Indoor Map Data Logging or
Signal Locate.
— For Outdoor Mapping: Record Save/Recall > File Folder Default
System
— Default – Sets the default User Folder path:
——List files (*.csv and *.kml) are save-recalled to:
"[CurrentDevice]:\RecordPlayback\CS\"
——Record-Play files are save-recalled to:
"[CurrentDevice]:\RecordPlayback\CS\"
Or
—
System – Sets the User Folder to the user defined system
folder path/name:
——List files are save to-from
"CurrentDevice\<UserSelectedFolder>\"
——Record-Play files are save-recalled to:
"CurrentDevice\<UserSelectedFolder>\"
Refer to “File Management” on page 817.
— Then File Type
— KML (default) or
— CSV
— Then
Save Log File.
or
— Then Recall Log File.
— Optional
Auto Save ON (default = OFF). To avoid loss of data, if
power loss occurs.
— Then Back
5. Set up indoor mapping press More > Indoor Map Data Logging then
choose
