Indoor and Outdoor Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option
233), and GPS Receiver (Option 307))
How to Set Up Mapping Settings
— To change your file settings or measurement interval.
Learn more, refer to
“To change Data Logging
Configuration settings:” on page 517.
— Press
Maps
– to open a softkey menu enable map view and related
features (e.g., Data Selection, Red/Blue Limits, Labels & Icons,
Zoom).
Then choose from the following:
——
View Map OFF ON To enable/disable the current
map view (default = latitude/longitude = 0.00/00.
Need GPS to view current location (default =
OFF).
——
Data Selection Opens a softkey menu to set the
active data channel, sort type, and sort order.
Then Choose:
——Red/Blue Limits
Opens a softkey menu to assign
power values to the red (high power limits) and
blue (low power limits) heat map display limits
(defaults: Red Limit = –20 dBm, Blue limit = –90
dBm).
——
Zoom Zoom in/out on the map displayed.
——
Labels & Icons Opens a softkey menu to
enable/disable map data point labels and icon
types.
Then choose from the following:
Channel 1
Sets the data channel being recorded.
Available channels will vary within each
mode.
Sort
Power Freq
Sets the type of measurement displayed
(Power or Frequency).
Sort Order
Up Down
Sets the sort order to ascending (Up)
greater power/frequencies displayed first
or descending (Down) lowest power or
frequency values displayed first.
Back
Returns to previous softkey menu.
Labels
OFF ON
Enables/Disables map data point labels.
When enabled, a label is displayed for every
map data point (e.g., “Data 1”). When
disabled, labels are not displayed for the
map data points.
