Keysight N9915-90020 User’s Guide 547
Interference Analyzer (SA Mode) – Option 236
Record/Playback (SA Option)
— Playback Trace Number Activated automatically when Paused. Allows you
to continue playback from a specific trace, or scroll through traces
manually. Enter a value between 1 and the total number of traces using the
numeric keypad, arrows, or the rotary knob.
— Stop Immediately stops playback. Then choose from the following:
— Play Start playback from trace 1.
—
Record Resume recording from the last recorded trace.
—
Record Playback Setup Return to the setup menu to change
Configuration settings or Close the session.
Playback Ref Line Controls the placement of the pink line across the
screen. The playback ref line is displayed 1 pixel
under the trace identified by a Playback Trace
Number. Said another way, the spectrogram trace
identified by Playback Trace Number is drawn 1 pixel
above the playback reference line.
Playback Ref Line is
only available for
spectrogram lines, but
not for Waterfall,
because there is no spectrogram line.
Playback Trace
Date/Time
This softkey launches a time/date entry dialog box.
With the time/date collected from that dialog, the
recorded trace with the time nearest (exact, or
previous to the entered time) is set to the Playback
Trace Number. This allows the user to jump to an
approximate time in the recording, rather than
navigating by index. See also, “Playback Trace
Date/Time Dialog Box” on page 549.
