Keysight N9915-90020 User’s Guide 559
Reflection Mode (SA Models) - Option 320
Reflection Mode Settings
How to perform Normalization
To Port 1, connect a known device (usually an Open or Short) to which
reflection measurements are to be normalized.
—Press Trace 6
—Then Normalize
The yellow data trace displays the current measurement with trace math
applied. The math operation symbol [D/M] is displayed on the lower left corner
of the screen. Learn more about Trace Math in
“All about Trace Math” on
page 760
.
Data interpolation is NOT supported. If the Resolution setting is changed
with Trace Math enabled, the FieldFox will disable the math operation.
