62 Keysight N9915-90020 User’s Guide
CAT (Cable and Antenna Test) Mode
2-Port Insertion Loss Measurements
—Press Sweep 3, then select a Resolution setting.
—Press Cal 5
, then perform a calibration. Learn more on “How to Perform a
Calibration” on page 127
.
— Connect the DUT and view the insertion loss measurement results.
When measuring very long lengths of cable, it may be necessary to increase
the sweep time. Learn how on
page 56. Learn how in the Supplemental Online
Help at:
https://rfmw.em.keysight.com/wireless/helpfiles/FieldFoxOnlineSupplement
alHelp/Home.htm
.
