100 Keysight E4980A/AL Precision LCR Meter
Configuring Measurement Conditions (Display and Function Related Settings)
MEAS SETUP page
4-
10, 20, 30, •••, 90
100, 200, 300, •••, 900, 999
Table 4-3 Resolution steps that apply when setting the trigger delay time with INCR + /
DECR -
Trigger delay time Resolution
0 s through 100 ms 100 s
100 ms through 1 s 1 ms
1 s through 10 s 10 ms
10 s through 100 s 100 ms
100 s through 999 s 1 s
For the relationship between the trigger delay time and step delay time,
refer to Figure 4-5 on page 102.
Table 4-2 Resolution steps that apply when setting the trigger delay time with INCR ++
/ DECR --
INCR ++ / DECR -- (s)
