Configuring Measurement Conditions (Display and Function Related Settings)
MEAS SETUP page
Step 3. Enter the reference value using the softkeys or entry keys. If you use the entry
keys to enter the value, the softkey labels change to unit labels (n, u, m, x1,
k).
1
Step 4. Using the cursor keys, select the DEV A field.
Step 5. Select the deviation mode for the primary parameter by pressing the
appropriate softkey:
Step 6. Using the cursor keys, select the (DEV) B field.
Step 7. Select the deviation mode for the primary parameter using the softkeys
described in Step 5.
Softkey Description
MEASURE If you want to use a particular device/component as the reference,
connect the DUT and press this key. Then the instrument measures
the DUT once and automatically fills the REF A and (REF) B fields
with the measured values, which now serve as the reference values.
1. If the primary parameter of the measurement function is C, the softkey labels show these units: p, n, u, m, x1.
Softkey Description
ABS Displays the deviation as the difference from the reference value.
% Displays the deviation as a percentage of the reference value.
OFF Turns OFF deviation measurement.
