Keysight E4980A User Manual

Keysight E4980A/AL Precision LCR Meter 19
Unpacking and Preparation
Checking the Shipment
Table 1-1 Items Packaged with the E4980A/AL
Name Product/Part
Number
Qty
Standard Accessories
- E4980A/AL E4980A/AL 1
-Power Cable
1
8120-4753 1
-USB Cable 82357-61601 1
-CD-ROM (of the manual and the sample program)
See footnote
2
1
-CD-ROM (of the Keysight IO Libraries suite)
See footnote
2
1
Options
-Manual (Option ABA)
• User’s Guide
See footnote
2
1
-Rack mount kit without handles (Option 1CM)
3
5063-9241 1
1. This accessory varies from country to country. For the power cable option, see
Table 1-3. A 3p-2p conversion adapter is not supplied.
2. The LCR meter will always be supplied with the latest versions of these items.
3. This accessory is not shown in
Figure 1-1. For how to install the rack mount kit,
refer to the attached manual.

Keysight E4980A Specifications

General

Frequency Range	20 Hz to 2 MHz
Basic Accuracy	0.05%
DC Bias Voltage	0 V to ±40 V
Measurement Functions	L, C, R, Z, D, Q
DC Bias Current	0 A to 20 mA (using external DC bias source)
Display	LCD
Interface	LAN, USB, GPIB
Dimensions	426 mm (W) x 177 mm (H)
Weight	13.5 kg
