Keysight E4980A/AL Precision LCR Meter 49
Display Format
MEAS DISPLAY Page
Equivalent parallel and serial combinations
The combinations of primary and secondary parameters, including the
equivalent parallel and series combinations, are listed below.
Rdc
2
DC resistance
1. This parameter can be set only when the E4980A/AL is equipped with option 001.
2. This parameter can be set only when the E4980A/AL is equipped with either
option 001, 030/032, 050/052, 100 or 200.
Table 3-3 Secondary parameter
Parameter Description
Table 3-4 Measurement function
Primary
parameter
Series mode Parallel mode
ZZ-r
Z-d
-----
Y ----- Y-r
Y-d
CCs-D
Cs-Q
Cs-Rs
Cp-D
Cp-Q
Cp-G
Cp-Rp
LLs-D
Ls-Q
Ls-Rs
Ls-Rdc
Lp-D
Lp-Q
Lp-G
Lp-Rp
Lp-Rdc
R R-X -----
G ----- G-B
Primary parameter Secondary parameter
Vdc Idc
Measurement function Vdc-Idc does not have the series mode and parallel
mode.
