50 Keysight E4980A/AL Precision LCR Meter
Display Format
MEAS DISPLAY Page
3-
Procedure for setting the measurement function
Step 1. Press the [Display Format] key.
Step 2. Press the MEAS DISPLAY softkey.
Step 3. Use the cursor keys to select the FUNC field.
Step 4. Use the softkeys to select the primary parameter.
Step 5. If the secondary parameter exists, select the secondary parameter from
measurement parameters displayed using the softkeys.
For the combinations of measurement parameters, refer to Table 3-1 on
page 47.
