Keysight E4980A/AL Precision LCR Meter 67
Display Format
MEAS DISPLAY Page
Step 5. Press [DC Bias] to set the DC bias output to ON. DCBIAS appears in the status
display area and the LED indicator for DC bias lights up in orange.
Settling time for the DC bias signal voltage
Changing the DC bias requires a few milliseconds to several tens of
milliseconds. For details, refer to DC bias settling time in data sheet in Chapter
11 “Specifications and Supplemental Information”
1. When option 001 is not installed, only 0 V, 1.5 V, and 2.0 V can be
set.
Table 3-21 DC bias signal current that can be set with INCR ++ / DECR
INCR ++ / DECR -- (A)
1
0,
1 , 2 , 3 , •••, 9 
10 , 20 , 30 , •••, 90 
100 , 200 , 300 , •••, 900 
1 m, 2 m, 3 m, •••, 9 m
10 m, 20 m, 30 m, •••, 90 m
100 m
1. This cannot be set when option 001 is not installed.
