66 Keysight E4980A/AL Precision LCR Meter
Display Format
MEAS DISPLAY Page
3-
Procedure for setting DC bias
Step 1. Press the [Display Format] key.
Step 2. Press the MEAS DISPLAY softkey.
Step 3. Use the cursor keys to select the BIAS field.
Step 4. Use the softkeys or numeric entry keys to enter the test signal level. When
data is entered with the numeric entry keys, the softkey labels are changed to
the appropriate unit labels (mV, V, uA, mA, A).
Idc (A) Vosc(Vrms) Vosc  2  1.15 + Idc  100.2 < 42 V
Idc (A) Iosc (Arms) Iosc  2  115 + Idc  100.2 < 42 V
Table 3-19 DC bias and test signal level-setting limits
Setting value Limit
DC bias Test signal
level
Softkey Function
INCR ++ Increases the oscillator’s output level with a resolution shown in
Table 3-20 or Table 3-21.
INCR + Increases the oscillator’s output level with a resolution shown in
Table 3-16 to Table 3-18.
DECR - Decreases the oscillator’s output level with a resolution shown in
Table 3-16 to Table 3-18.
DECR -- Decreases the oscillator’s output level with a resolution shown in
Table 3-20 or Table 3-21.
Table 3-20 DC bias signal voltage that can be set with INCR ++ / DECR --
INCR ++ / DECR -- (V)
1
0,
100 , 200 , 300 , •••, 900 
1 m, 2 m, 3 m, •••, 9 m
10 m, 20 m, 30 m, •••, 90 m
100 m, 200 m, 300 m, •••, 900 m
1, 2, 3, •••, 9
10, 20, 30, 40
