Krone MX 310 GL - Unloading Process; GL Design; GD Design

Operation
157
Pos: 25.14.6 /Üb erschriften/Üb erschriften 2/A-E/D er Entlade vorgang @ 0\m od_119979708 5544_78.doc @ 35015
11.8 Unloading Process
Pos: 25.14.7 /B A/Sicherheit/Ge fahrenhinweise /Ladewagen/H eckklappe öff nen @ 0\mod_ 11997968212 94_78.doc @ 34996
Warning!
Opening the tailgate
Effect: Injuries or damage to the machine
• No one is permitted in the swivel range when opening the tailgate.
Pos: 25.14.8 /B A/Bedienung /L adewagen/Hec klappe/Heckkla ppe öffnen. @ 0 \mod_1199 797321950_78. doc @ 35034
Opening the tailgate.
Pos: 25.14.9 /Üb erschriften/Üb erschriften 3/A-E/ GL-Ausführ ung @ 0\mod _119979931760 6_78.doc @ 35 186
11.8.1 GL Design
Pos: 25.14.10 / BA/Bedienung / Ladewagen/Kra tzboden/Kratzb oden zusch alten GL @ 0\mo d_119979942 6653_78.doc @ 35205
Switch on the floor conveyor and move forward quickly so that the unloaded material can fall
freely.
Pos: 25.14.11 /Ü berschriften/Ü berschriften 3/A- E/GD-Ausführ ung @ 0\mod _1199799256 560_78.doc @ 3 5167
11.8.2 GD Design
Pos: 25.14.12 / BA/Bedienung / Ladewagen/Hec klappe/Hin weis Heckklappe öffnen GD @ 0\ mod_119979 7369763_78.doc @ 35053
Note
As the tailgate opens, the switching cylinder for the discharge roller switch is
actuated automatically. To ensure the discharge rollers switch reliably, hold
down the key for opening the tailgate for another 1 - 2 seconds after the
tailgate is completely open.
Pos: 25.14.13 / BA/Bedienung / Ladewagen/Za pfwelle einschalt en. @ 0\mod _1199797573 106_78.doc @ 3 5072
Switching on PTO shaft.
Pos: 25.14.14 / BA/Sicherheit/G efahrenhin weise/Ladewagen/Sc halten der Z apfwelle @ 0\m od_119979783 0763_78.doc @ 35091
Caution!
Switching of the PTO shaft
Effect: Material Damages
Switching of the PTO shaft during the unloading process only when operating
on idle and the tailgate is open.
Pos: 25.14.15 / BA/Bedienung / Ladewagen/Kra tzboden/Kratzb oden zusch alten GD @ 0\ mod_1199798212 263_78.doc @ 35129
• Switch on the floor conveyor and adjust the speed according to the load, pressing or
loading height.
• Use rapid traverse only for residual unloading.
Note
The floor conveyor operates only when the tailgate is completely open and
the discharge rollers are rotating.
