13.8 Display hydraulic block Comfort
Magnetventile
Funktionen
Funktionsschaubild
1.) 2.) 3.)
Y1
Not-Handbetätigung
Y6 Y7
Y10 Y11 Y8 Y9
Y5 Y18Y14 Y15
Y4
Y3
Fkt.1
Fkt.2
27 005 706 0
Y5
Y7
Y18
Y6
Y10
Y15
Y14
Y11
Y8
Y9
Y4
Y3
Y1
ON
OFF
Figure 118:
Y1 Floor conveyor supply Y6,Y7 Tailgate
Y3 raise/lower Y8,Y9 Drawbar
Y4 raise/lower Y10,Y11 Cutter
Y5Y18 Pick-up Y14 Discharge roller coupling
Y15 Steering axle locked
