14.6 Lubrication points (GD)
The following table contains a list of lubrication points on the machine and the number of
lubrication nipples.
Lubrication points Number of
lubrication
points
1) Bearing for conveyor drum right + left (MX 310 / MX 350) 2 / 1
2) Parking brake lever 1
3) Steering knuckle of the steering axle (optional additional equipment) 4
4) Locking cylinder of the steering axle (optional additional equipment) 2
5) Chain lubrication system discharge rollers 1
6) Bearing for lower discharge roller/floor conveyor switching 1
7) Floor conveyor, rear 4
8) Compensatory swing (right/left) (for longitudinal control unit only) 2
9) Tandem axle - brake shaft / automat. linkage setter 8 / 4
10) Floor conveyor, front 4
11) Guide wheel arm for pick-up 2
12) Guide wheel for pick-up 2
13) Main drive PTO shaft 8
14) Hitch (for revolving hitch only) 1
15) Chain lubrication system for rotor drive chain (MX 310 only) 1
16) Coupling for discharge roller mechanism, front 2
