Commissioning
31
Pos: 12.1 /Übersc hriften/Übersc hriften 1/A-E/Ers tinbetriebn ahme @ 0\mod _119631420149 8_78.doc @ 58 55
5 Commissioning
Pos: 12.2 /BA/Ersti nbetriebnah me/Ladewagen/ Aus Transpor tgründen @ 0\m od_119970 1971522_78.doc @ 33305
For transport reasons, the machine is delivered without the PTO shaft mounted and with the
panelling not completely mounted. Before initial start-up, the machine must be completely
assembled and adjusted to the tractor type. The following parts are included loose with delivery.
These parts should be kept in the loading area of the machine
Pos: 12.3 /BA/Ersti nbetriebnah me/Ladewagen/ Aus Transpor tgründen Bild Tit an_AX_ZX @ 0\mod_119 9702167491_78 .doc @ 33345
TR000009
1
4
5
7
3
2
Figure 5
Pos: 12.4 /BA/Ersti nbetriebnah me/Ladewagen/ Aufzählung M ontageteile M X @ 14\mod_1 231427915350_ 78.doc @ 172 142
Item not shown in figure Pcs.
1 PTO shaft 1 Stake 4
2 Control (optional) 2 End wall 1
3 Electrical cable for lighting 3 Baffle plate 1
4 Can of spray paint 4 Platform gate right 1
5 Operating Instructions Platform gate left 1
7 Small parts (in cardboard box) 8 Hood plate centre 1
9 Side sheet right 1
Side sheet left 1
not shown in figure
10 Hood sheet top 1
Power supply cable 11 Sensor plate 1
Insert pocket (optional) 12 Sensor support 1
Standard control unit (optional)
Cable harness for terminal connection (optional)
Supports (optional)
Holding device with suction cup (optional)
Lever
